A17-5T300/480/3PRS

Spec Sheet IES File LM79 Instructions Sell Sheet Folleto (Español) Family Spec Sheet Spec Sheet EZ Layout

A17-5T300/480/3PRS

300W 3000/4000/5000K

0-10V Dimming, standard

100,000-hour LED lifespan

5-Year, limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	300/240/200W
Color Temp	3000/4000/5000K
Lumens	33,202-47,384 lm
Efficacy	144.7-168.2 lm/W
Color Accuracy	81-84 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	/480
208V
240V
277V
Input Watts	207.6-302.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 11.5 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

IP Rating

Ingress protection rating of IP65 for dust and water

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Electrical

Driver

300W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.64A
240W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.54A
200W: Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.45A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

4.61% at 480V

Power Factor

96.09% at 480V

Surge Protection

6 kV

3-Pin Receptacle with Shorting Cap

ANSI C136.41 3-pin receptacle, compatible with wireless control systems

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Optical

IES Classification

The Type V distribution produces light in a wide and uniform 360° pattern that is perfect for large outdoor areas such as parking lots, corporate parks and retail settings

BUG Rating

B5 U0 G3

LED Characteristics

LEDs

Long-life, high-efficiency, surface-mount LEDs

Color Uniformity

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Construction

Cold Weather Starting

The minimum starting temperature is -40°F (-40°C)

Maximum Ambient Temperature

Suitable for use in up to 104°F (40°C)

Lens

Polycarbonate lens

Housing

Die-cast aluminum housing, lens frame and mounting arm

Vibration Rating

3G vibration rating per ANSI C136.31

Effective Projected Area (Without Shield)

1 Fixture: 0.72 ft²
2 Fixtures at 90°: 1.04 ft²
2 Fixtures at 180°: 1.43 ft²
3 Fixtures at 90°: 1.76 ft²
4 Fixtures at 90°: 1.76 ft²

Effective Projected Area (With Shield)

1 Fixture: 0.75 ft²
2 Fixtures at 90°: 1.39 ft²
2 Fixtures at 180°: 1.5 ft²
3 Fixtures at 90°: 2.15 ft²
4 Fixtures at 90°: 2.15 ft²

Finish

Formulated for high durability and long-lasting color

Green Technology

Mercury and UV free. RoHS-compliant components.

Installation

Mounting

Universal mounting arm compatible for hole spacing patterns from 1" to 5 1/2" center to center. Round Pole adapter plate included as a standard. Easy slide and lock to mount fixture with ease. Round pole diameter must be >4" to mount fixtures at 90° orientation.

Other

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
