DRI-21-EMGR-DC-D10
DRI-21-EMGR-DC-D10
- For use with select RAB Commercial Downlights
- Meets UL924 Requirements
Dimensions
Weight: 3.2 lbs
Technical Specifications
Performance
Product Type
Emergency Driver
Description
Field installable battery back up for direct mount downlights, see Downlight Accessory Compatibility Guide.
Input Power (W)
8W
Output Power
20W
L70 Lifespan
50,000-Hour LED lifespan based on IES LM-70 results
Electrical
Input Voltage
100-277V
Output Voltage
200VDC
Operating Frequency
50/60Hz
Operating Temperature
32°F to 140°F (0°C to 60°C)
Battery Operation
90 minutes
Battery Type
Lithium
Recharge Time Required
24-hours
Discharge Temperature
32°F to 140°F (0°C to 60°C)
Storage Temperature
-4°F to 113°F (-20°C to 45°C)
Storage Shelf Life
1-year
Installation
Mounting
Recessed Housing
Construction
Shape
Rectangle
Finish
Red
Enclosure Material
Metal
Compliance
Listings
UL924 Listed
Environment
Suitable for use in dry and damp environments
IC Rated
No
Certification Model Number
DRI-21-EMGR-DC-D10
T20 Compliant
Can be used to conform with the requirements of California Title 20
California Title 24 JA8 Compliant
Not Compliant
California Energy Commission (CEC) Status
Lawful for Sales in California
RoHS
Mercury and UV free. RoHS-compliant components.
FCC
Complies with Part 15B of the FCC Rules
Other
Compatible Products
See Downlight Accessory Compatibility List for a complete listing of compatible products.
5-Year Limited Warranty
The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
