EXITOUT-GC

Spec Sheet EM Remote Head Compatibility List Instructions Spec Sheet

EXITOUT-GC

Single-face panel with color letters

Durable thermoplastic design

Rated for us indoor and outdoor in dry, damp, and wet environments.

Compliant with California Title 20

View Technical Specs

View Price & Availability

Dimensions

Weight: 3.6 lbs

Technical Specifications

Performance

Product Type

Outdoor Exit Sign

Description

Outdoor exit sign with a single face and green letters. Wet and cold weather rated.

Input Wattage

3.3W

Electrical

Power Factor

≥0.9

Input Voltage

Dual 120/277 Voltage

Operating Frequency (Hz)

60Hz

Input Current @ 120V (mA)

30mA

Input Current @ 277V (mA)

14mA

Dual Voltage Circuit Operation

Operating Temperature

-4°F to 122°F (-20°C to 50°C)

Emergency Illumination

90 minutes

Battery Type

Nickel Cadmium

Battery Voltage

4.8V

Recharge Time Required

24-hours

Battery Operating Temperature

-20°F to 50°F (-4°C to 122°C)

Storage Temperature

68°F to 86°F (20°C to 30°C)

Storage Shelf Life

3 years before the initial charge. 5 years after initial charge.

Self Diagnostics

No, manual test only

Remote Test Switch

Emergency Backup

Battery Backup

Yes

Installation

Mounting Method

Back/Top/End

Mounting Type

Wall/Ceiling Mount

Cold Weather Rated

Yes

Construction

Shape

Rectangle

Housing Material

Thermoplastic

Panel Material

Thermoplastic

Panel Color

White

Letter Color

Green

Housing Color

White

Number of Faces

Single Face

Arrow Direction

No Arrow

Sign Format

Stencil

Remote Capacity

Compliance

Listings

UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards

Environment

Suitable for indoor or outdoor use in dry, damp, and wet environments

IP Rating

Outdoor

Certification Model Number

WLEZXTEU1GWEM-CW

T20 Compliant

Can be used to conform with the requirements of California Title 20

California Title 24 JA8 Compliant

Not applicable

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Battery is prorated.
