FXLED500TYB64/480/D10/PCS4
FXLED500TYB64/480/D10/PCS4
- 500W replaces 1500W MH floodlights
- 100,000-hour LED lifespan
- 5-Year, No-Compromise Warranty
Performance
| Watts | 500W |
| Color Temp | 3000K (Warm) |
| Lumens | 61,574 lm |
| Efficacy | 120.1 lm/W |
| Color Accuracy | 72 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 512.7W |
Dimensions
Weight: 71.0 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP66 for dust and water
Electrical
Drivers
Constant Current, Class 1, 480, 50/60 Hz, 480V: 1.08A
THD
9.73% at 480V
Power Factor
96.6% at 480V
Surge Protection
4 kV
Photocell
480V Swivel photocell included. Photocell is only compatible with 480V.
Optical
NEMA Type
NEMA Beam Spread 6H x 4V
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 1,500W Metal Halide
LED Characteristics
LEDs
Multip-chip, high-output, long-life LEDs
Color Stability
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
Vibration Rating
2G vibration rating per ANSI C136.31
Cold Weather Starting
The minimum starting temperature is -40°F (-40°C)
Ambient Temperature
Suitable for use in up to 104°F (40°C)
Effective Projected Area
EPA = 4
Thermal Management
Superior thermal management with external "Air-Flow" fins
Housing
Die-cast aluminum housing with lens frame
Reflector
Specular vacuum-metalized polycarbonate; semi-specular on flat trim edge
Lens
Clear glass lens
Gaskets
High-temperature silicone gaskets
Finish
Formulated for high durability and long-lasting color
Green Technology
Mercury and UV free. RoHS-compliant components.
Installation
Mounting
Heavy-duty Trunnion mount with stainless steel hardware
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
