HAZSHARK4
HAZSHARK4
- Class 1, Division 2, Groups A, B, C, D
- Class 2, Division 1, Groups E, F, G
- Class 2, Division 2, Groups F, G
- Class 3
- IP66, UL1598, UL8750 and UL 844 ratings
- DLC Listed
- 50,000-Hour LED lifespan
- 5-Year, no-compromise warranty
Performance
| Watts | 50W |
| Color Temp | 5000K |
| Lumens | 7,024 lm |
| Efficacy | 143.3 lm/W |
| Color Accuracy | 84 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.41A |
| 208V | 0.24A |
| 240V | 0.21A |
| 277V | 0.19A |
| Input Watts | 49W |
Dimensions
Weight: 19.7 lbs
Technical Specifications
Hazardous Location Classifications
Class 1, Division 2 (Groups A, B, C, D)
Class 1 (Hazardous Material in Surrounding Atmosphere):
Flammable vapors or gases may be present
Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions
Groups A, B, C, D (Hazardous Material in Surrounding Atmosphere):
A = Acetylene
B = Hydrogen, butadiene, ethylene oxide, propylene oxide and acrolein
C = Ethylene, cyclopropane and ethyl ether
D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene
Flammable vapors or gases may be present
Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions
Groups A, B, C, D (Hazardous Material in Surrounding Atmosphere):
A = Acetylene
B = Hydrogen, butadiene, ethylene oxide, propylene oxide and acrolein
C = Ethylene, cyclopropane and ethyl ether
D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene
Class 2, Division 1 (Groups E, F, G)
Class 2 (Hazardous Material in Surrounding Atmosphere):
Combustible dust may be present
Division 1 (Presence of Hazardous Materials):
Ignitable concentrations of hazard exists under normal operating conditions
Groups E, F, G (Hazardous Material in Surrounding Atmosphere):
E = Combustible metal dusts: aluminum, commercial alloys and magnesium
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood
Combustible dust may be present
Division 1 (Presence of Hazardous Materials):
Ignitable concentrations of hazard exists under normal operating conditions
Groups E, F, G (Hazardous Material in Surrounding Atmosphere):
E = Combustible metal dusts: aluminum, commercial alloys and magnesium
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood
Class 2, Division 2 (Groups F, G)
Class 2 (Hazardous Material in Surrounding Atmosphere):
Combustible dust may be present
Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions
Groups F, G (Hazardous Material in Surrounding Atmosphere):
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood
Combustible dust may be present
Division 2 (Presence of Hazardous Materials):
Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions
Groups F, G (Hazardous Material in Surrounding Atmosphere):
F = Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts
G = Other combustible dusts: chemicals, flour, grain, plastic and wood
Class 3
Class 3 (Hazardous Material in Surrounding Atmosphere):
Easily ignitable flyings or fibers may be present
Easily ignitable flyings or fibers may be present
UL 844
Electric lighting fixtures for use in hazardous (classified) locations
Compliance
UL Listed
Suitable for wet locations
UL Marine Listed
Marine Listed Outside Type (Saltwater)
IP Rating
Ingress protection rating of IP66 for dust and water
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: S-1MDUOR (Hazardous Environment Low-Bay)
DLC Product Code: S-3V8FBW (Hazardous Direct Linear Ambient Luminaires)
DLC Product Code: S-1MDUOR (Hazardous Environment Low-Bay)
DLC Product Code: S-3V8FBW (Hazardous Direct Linear Ambient Luminaires)
Electrical
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
1.47% at 120V, 3.24% at 277V
Power Factor
99.6% at 120V, 92.0% at 277V
Surge Protection
4 kV
Construction
Housing
Stainless steel
Rated Ambient Temperature Range
-40°F (-40°C) to 122°F ( 50°C), T5
Lens
Clear polycarbonate* lens.
*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.
*Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.
Gaskets
High-temperature silicone
Green Technology
Mercury and UV free. RoHS-compliant components.
Finish
Formulated for high durability and long-lasting color
Installation
Mounting
Two mounting options included: stainless steel, surface mount brackets or aircraft cable for suspended mount.
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Stability
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
