IVAT2-100LPA750ZH/WS4/LC
Performance
| Watts | 94W |
| Color Temp | 5000K (Cool) |
| Lumens | 11,058 lm |
| Efficacy | 114.9 lm/W |
| Color Accuracy | 75 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 96.2W |
Dimensions
Weight: 15.0 lbs
Technical Specifications
Installed with Lightcloud
Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.
Learn MoreLightcloud
Lightcloud Controller Installed
Fixture, Zone, and plug-load control from one powerful device. Capable of switching, 0-10V dimming, power monitoring. Can also be used to extend the range of the Lightcloud mesh network. Attach to fixture, junction box, or electrical panel. Learn more at www.lightcloud.com
Compliance
UL Listed
Suitable for wet locations
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Title 24 Compliant
An IVELOT edge-lit area light can be used with a motion sensor or photocell control option to comply with 2016 Title 24 Part 6 Section 130.2 (a,b,v)
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-N42Z5D
DLC Product Code: S-N42Z5D
Electrical
Driver
Class 2, 50/60Hz, 480V 4kV standard, 10kV optional
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
12.31% at 480V
Power Factor
96% at 480V
Recently Viewed Products
HALVS18L940-F-S/BL
Architectural 1906 Lumens Halvs Forward & Up/Down Light 25W 90Cri 4000K Frosted Lens Silver Finish Bi-Level Control
HALV18L930-CW-SA/E2
Architectural 619 Lumens Halv Forward Light 25W 90Cri 3000K Crushed Polar White Satin Nickel Finish Battery Backup
HALVS18L927-MA-SA
