Suitable for wet locations

Ingress protection rating of IP66 for dust and water

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Can be used to conform with the requirements of California Title 24 Part 6.

Long-life, high-efficacy, surface-mount LEDs

LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Class 2, 50/60Hz, 120-277V, 4kV standard, 10kV optional, 120V: 0.24A, 208V: 0.14A, 240V: 0.12A, 277V: 0.11A

10.51% at 120V, 14.89% at 277V

98.8% at 120V, 91.3% at 277V

Battery backup will operate the LED Lamp for 90 minutes if power fails. Wired for 120V-277V.

0.273

Up to 100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

The minimum starting temperature is -4°F (-20°C)

Suitable for use in up to 104°F (40°C)

Diffused Polymethyl Methacrylate (PMMA)

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Surface mount standard (accessories available for wall, pole and trunnion mount)

/WS2 sensor options use state-of-the-art surface mount technology (SMT), just like cellular phones and beepers. SMT gives you more reliability, greater RFimmunity. This compact sensor that can fit neatly where others cannot. This sensor technology automatically affects the state of operation for lighting systems or individual luminaries based upon detecting the presence or absence of movement for both people as they exit/enter, or for the motion of moving vehicles within the sensors viewing area. The wide 180° viewing angle can detect movement along the entire side of a building with only one compact sensor. The hard lens is molded as part of the case, vandalproof, rainproof, bugproof and absolutely sealed. Sensor functions best when movement is across its detection pattern, not towards the sensor.

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
