LOT3T160/D10/WS4

Spec Sheet Instructions Spec Sheet

DISCONTINUED

LOT3T160/D10/WS4

Lightweight design and low EPA minimize pole load

Best-in-class 5-G vibration rating

100,000-hour LED lifespan

View Technical Specs

Performance

Watts	160W
Color Temp	5000K (Cool)
Lumens	22,436 lm
Efficacy	139.9 lm/W
Color Accuracy	76 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	1.35A
208V	0.78A
240V	0.67A
277V	0.59A
Input Watts	160.4W

Dimensions

Weight: 20.9 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PNUY5HSP

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 1.35A, 208V: 0.78A, 240V: 0.67A, 277V: 0.59A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

8.3% at 120V, 13.67% at 277V

Power Factor

99.5% at 120V, 93.2% at 277V

Surge Protection

L-N 4 kV; L-L, L-GND 6 kV

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Optical

IES Classification

The Type III distribution is meant to be located near the side of an area, projecting the light outward to fill the area. Ideal for roadways, general parking areas, lighting applications and where a large pool of light is required.

Construction

Effective Projected Area

EPA = 0.8
