LOT3T65YW/480/D10/UPA/5PR

Spec Sheet Instructions Spec Sheet

DISCONTINUED

Lightweight design and low EPA minimize pole load

Best-in-class 5-G vibration rating

100,000-hour LED lifespan

View Technical Specs

Performance

Watts	65W
Color Temp	3000K (Warm)
Lumens	8,017 lm
Efficacy	132.5 lm/W
Color Accuracy	72 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	60.5W

Dimensions

Weight: 20.9 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: P5Z4E7RQ

Electrical

Driver

Constant Current, Class 2, 480V, 50/60 Hz, 480V: 0.13A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

8.44% at 480V

Power Factor

98.1% at 480V

5-Pin Receptacle

ANSI C136.41 5-pin receptacle, compatible with wireless control systems

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Optical

IES Classification

The Type III distribution is meant to be located near the side of an area, projecting the light outward to fill the area. Ideal for roadways, general parking areas, lighting applications and where a large pool of light is required.

Construction

Effective Projected Area

EPA = 0.8
