LOT4T160NW/480/D10/HS
DISCONTINUED
LOT4T160NW/480/D10/HS
- 100,000-hour LED lifespan
- Type IV distribution
Performance
| Watts | 160W |
| Color Temp | 4000K (Neutral) |
| Lumens | 20,004 lm |
| Efficacy | 132.4 lm/W |
| Color Accuracy | 73 CRI |
| L70 Lifespan | 100,000 Hours |
| Type | Constant Current |
| 120V | |
| 208V | |
| 240V | |
| 277V | |
| Input Watts | 151.1W |
Dimensions
Weight: 20.9 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
Electrical
Driver
Constant Current, Class 2, 480V, 50/60 Hz, 480V: 0.33A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
6.76% at 480V
Power Factor
98.8% at 480V
Surge Protection
L-N 4 kV; L-Earth 6 kV
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Optical
IES Classification
The Type IV distribution (also known as a Forward Throw) produces a semicircular distribute, and is especially suited for mounting on sides of buildings or walls and perimeter of parking areas
Construction
Effective Projected Area
EPA = 0.8
