PAR38FA-19-9CCT-40D-DIM

Spec Sheet IES File Dimmer Compatibility List LM79 FCC Caution Spec Sheet EZ Layout

Replacement for high-output incandescent/halogen or ceramic metal halide

Adjustable CCT to choose from 3000/4000/5000K

Rated for use in enclosed fixtures in dry, damp, or wet locations

90+CRI provides high quality color rendering

Shatterproof enclosure for rugged applications

View Technical Specs

View Price & Availability

Performance

Watts	19W
Color Temp
Lumens	1,800 lm
Efficacy	95
Color Accuracy	3000/4000/5000K CRI
L70 Lifespan

Input Voltage	120V
Power Factor	0.9
Flicker	N/A
THDi	<20%

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 0.4 lbs

Technical Specifications

Performance

Product Type

PAR

Input Wattage

19W

Lumens

1,800lm

Efficacy

163.6lm/W

L70 Lifespan

15,000-Hour LED lifespan based on IES LM-70 results

Wattage Equivalency

150W Halogen

Compliance

Enclosed Fixtures

Suitable for use in enclosed fixtures

LED Characteristics

Color Temperature

3000/4000/5000K

Color Accuracy (CRI)

90 CRI

Beam Angle

40°

Electrical

THD

<20%

Power Factor

0.9

Dimmable

Yes, dimmable down to 10% on compatible TRIAC/ELV dimming systems.

Operating Temperature

-20°C to 45°C (-4°F to 113°F)

Input Voltage

120V

Operating Frequency

60 Hz

Construction

Shape

PAR38

Endcap Material

Aluminum

Enclosure Material

Plastic

Installation

Base Type

E26 Edison

Other

3-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
