Suitable for damp locations

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: S-MZYW6B

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Equivalent to 400W Metal Halide

Long-life, high-efficacy, surface-mount LEDs

3-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

LED Color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Constant Current, Class 2, 120-277V, 50/60Hz, 120V: 1.13A, 208V: 0.66A, 240V: 0.57A, 277V 0.50A

3.01% at 120V, 7.86% at 277V

99.9% at 120V, 95.1% at 277V

6 kV

Battery backup will operate the fixture for 90 minutes if power fails. Wired for 120-277V.

0.37

The minimum starting temperature is -4°F (-20°C)

Suitable for use in up to 113°F (45°C)

Extruded aluminum

Polycarbonate lens

Polyethylene Terephthalate (PET)

V hooks (chain by others)

Integrated/embedded networked lighting control, luminaire-level lighting control. Fixture, Zone, and plug-load control from one powerful device. LLLC - capable of switching, 0-10Vdimming, power/energy monitoring. Can also be used to extend the range of the Lightcloud mesh network communication protocols. Offers the capability to set the maximum light output to a less-than-maximum state of an individual luminaire at the time of installation or commissioning. The High-End trim functionality is field reconfigurable via the Lightcloud mesh network communication protocols. The Lightcloud controller can be attached to the fixture, junction box, or electrical panel.
DLC system - N1XMLOEATBA
Learn more at www.lightcloud.com

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
