Performance
Watts 10W
Color Temp
Lumens 800 lm
Efficacy 80 lm/W
Color Accuracy 2700K-6500K CRI
L70 Lifespan
Input Voltage 120V
Power Factor >0.9
Flicker N/A
THDi N/A
Dimensions
Link to Dimension Drawing

Weight: 0.3 lbs

Technical Specifications

Installed with Lightcloud

Lightcloud is a commercial wireless lighting control system fully developed and supported by RAB. It's powerful and flexible, yet easy to use and install.

Learn More
Performance
Product Type
A-Line
Input Wattage
10W
Wattage Equivalency
60W Incandescent
Lumens
800lm
L70 Lifespan
25,000 Hours
Construction
Shape
A19
Installation
Base Type
E26 Edison
Electrical
Power Factor
>0.9
Operating Temperature
-20°C to 40°C
Input Voltage
120V
Operating Frequency
60 Hz
LED Characteristics
Beam Angle
230°
Other
3-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of three (3) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
Compliance
Damp Rated
Suitable for damp locations
UL Listed
Yes
Enclosed Fixtures
Suitable for use in enclosed fixtures
T20
Complies with CEC Title 20
T24 JA8 Compliant
Complies with Title 24 Appendix JA8
FCC
Yes
