A34-5T105SFN/WS4
Performance
| Watts | 105W |
| Color Temp | 4000K (Neutral) |
| Lumens | 15,326 lm |
| Efficacy | 144.7 |
| Color Accuracy | 82 CRI |
| L70 Lifespan | 50,000 Hours |
| Type | Constant Current |
| 120V | 0.90A |
| 208V | 0.51A |
| 240V | 0.44A |
| 277V | 0.40A |
| Input Watts | 105.9W |
Dimensions
Weight: 17.7 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations
T24 JA8 Compliant
Can be used to conform with the requirements of California Title 24 Part 6.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: S-XHWEJ0
DLC Product Code: S-XHWEJ0
Electrical
Driver
Constant Current, Class 1, 120-277V, 50/60Hz, 120V: 0.90A, 208V: 0.51A, 240V: 0.44A, 277V: 0.40A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%.
THD
2.97% at 120V, 4.72% at 277V
Power Factor
99.8% at 120V, 97.29% at 277V
Performance
Lifespan
50,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
