EREMOTE-HS

Spec Sheet EM Remote Head Compatibility List Instructions Spec Sheet

EREMOTE-HS

Durable thermoplastic design

Remote head capable, see Remote Head Compatibility List

View Technical Specs

View Price & Availability

Dimensions

Weight: 0.6 lbs

Technical Specifications

Performance

Product Type

Emergency Unit, Remote Head

Description

Indoor Thermoplastic Remote Double Head

Lumens

65lm

Lumens (per fixture)

130lm

Electrical

Input Voltage

Multi-Volt (3.6V,9.6V,6V,12V)

Dual Voltage Circuit Operation

Operating Temperature

32°F to 122°F (0°C to 50°C)

Self Diagnostics

Yes

Remote Test Switch

Installation

Mounting Method

Back

Mounting Type

Wall

Maximum Mounting Height (ft.)

15 ft

Emergency Egress Coverage(ft) Mounting at height of 7.5ft

8 ft x 3 ft mounted @ 7.5 ft

Spacing Criteria for Emergency Egress

17 ft on center assuming 7.5 ft mounting height with egress path 3 ft out

Cold Weather Rated

Application

For Use With Fixtures With Self-Diagnostic Option

Construction

Shape

Rectangle

Housing Material

Thermoplastic

Housing Color

White

No. of Heads

2-Lamp Heads

Head Shape

Square

Remote Head Power (W)

Compliance

Listings

UL924 Listed

Environment

Suitable for indoor use in dry and damp environments

IP Rating

Indoor

Certification Model Number

RHLED2SDT-MV-HL

T20 Compliant

Not applicable

California Title 24 JA8 Compliant

Not applicable

California Energy Commission (CEC) Status

Lawful for Sales in California

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

See Remote Head Compatibility List

5-Year, No-Compromise Warranty

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
