FXLED125TYW/7PRS
FXLED125TYW/7PRS
- 66% energy cost savings vs. HID
- NEMA Type - 6H x 6V
- "Air-Flow" technology heat dissipation
- 100,000-hour LED lifespan
- 5-Year, No-Compromise Warranty
Performance
| Watts | 125W |
| Color Temp | |
| Lumens | 17,594 lm |
| Efficacy | 128.7 lm/W |
| Color Accuracy | |
| L70 Lifespan |
| Type | Constant Current |
| 120V | 1.20A |
| 208V | 0.69A |
| 240V | 0.60A |
| 277V | 0.52A |
| Input Watts | 136.7W |
Dimensions
Weight: 25.4 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for mounting within 4 ft (1.2m) of the ground.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
IP Rating
Ingress protection rating of IP66 for dust and water
Performance
Lifespan
100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations
Wattage Equivalency
Equivalent to 400W Metal Halide
LED Characteristics
LEDs
Long-life, high-efficacy, surface-mount LEDs
Color Stability
LED color temperature is warrantied to Shift no more than 200K in color temperature over a 5-year period
Color Uniformity
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Construction
EPA
2
Maximum Ambient Temperature
Suitable for use in up to -40°F (-40°C) to 104°F (40°C )
Lens
Tempered glass lens included
Housing
Die-cast aluminum housing and door frame
Finish
Formulated for high durability and long-lasting color
Installation
Mounting
Heavy-duty Trunnion mount with stainless steel hardware
Electrical
Driver
Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 1.14A, 208V: 0.66A, 240V: 0.57A, 277V: 0.50A
THD
1.99% at 120V, 10.38% at 277V
Power Factor
99.4% at 120V, 96.5% at 277V
7-Pin Receptacle with Shorting Cap
ANSI C136.41 7-pin receptacle, compatible with wireless control systems
Other
5-Year, No-Compromise Warranty
RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
