LOT3T65W/D10/UPA/PCT

Spec Sheet Instructions Spec Sheet

DISCONTINUED

Lightweight design and low EPA minimize pole load

Best-in-class 5-G vibration rating

100,000-hour LED lifespan

View Technical Specs

Performance

Watts	65W
Color Temp	5000K (Cool)
Lumens	8,531 lm
Efficacy	136.9 lm/W
Color Accuracy	76 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V	0.55A
208V	0.33A
240V	0.29A
277V	0.25A
Input Watts	62.3W

Dimensions

Weight: 20.9 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

DLC Listed

This product family is listed with the DesignLights Consortium (DLC). Individual SKUs within this family may carry either a DLC Standard or DLC Premium qualification. Please refer to the individual product specification sheet or the DLC Qualified Products List (QPL) at designlights.org to confirm the qualification status of a specific SKU prior to specification or purchase.

Electrical

Driver

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.55A, 208V: 0.33A, 240V: 0.29A, 277V: 0.55A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

7.07% at 120V, 6.88% at 277V

Power Factor

99.6% at 120V, 94.4% at 277V

Photocell

120-277V Twistlock photocell included. Photocell is compatible with 120-277V.

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Optical

IES Classification

The Type III distribution is meant to be located near the side of an area, projecting the light outward to fill the area. Ideal for roadways, general parking areas, lighting applications and where a large pool of light is required.

Construction

Effective Projected Area

EPA = 0.8

LED Characteristics

LEDs

Long-life, high-efficacy, surface-mount LEDs
