MDLED1X12D10-30Y-W

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

MDLED1X12D10-30Y-W

Single 12 Watt LED head

Fixture head rotates a full 360° and tilts up to 45°

Easily lock head in place with a thumb screw

Tool-less adjustment for 3 discrete positions: full recess, flush mount or semi-recessed

View Technical Specs

View Price & Availability

Performance

Watts	12W
Color Temp	3000K (Warm)
Lumens	924 lm
Efficacy	60 lm/W
Color Accuracy	90 CRI
L70 Lifespan

Type	Constant Current
120V	0.12A
208V	0.08A
240V	0.07A
277V	0.06A
Input Watts	15.4W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 2.8 lbs

Technical Specifications

Compliance

UL Listed

Suitable for damp locations

IC Rated

Suitable for direct contact with insulation

Construction

Gear Tray Component

This component must be ordered with Remodeler or New Construction housing in order to make a complete fixture. See here for Remodeler housing.
See here for New Construction housing.

Brackets

Butterfly brackets allow mounting with 1/4 x 1/2" bar stock, C Channel, 1/2" conduit, or nailer bars

Cold Weather Starting

The minimum starting temperature is -10°C/14°F Ambient Temperature

Electrical

Driver

0-10V, Constant Current, Class 2, 120-277V, 50/60Hz,350mA, 120V 0.17A, 277V 0.09A, Power Factor 99.4%, THD≤10%, Minimum Operating Temp 14° F (-100°C).

Dimming Driver

0-10V compatible dimmer as low as 10%. See compatibility guide here.

LED Characteristics

LED

High-output, long-life LED with 2 step binning and integrated driver technology
