PIP45W/D10/PCU
PIP45W/D10/PCU
- 0-10V Dimming, standard
- Replaces 150W MH
- 60,000-Hour LED lifespan
- 5-Year, limited warranty
Performance
| Watts | 45W |
| Color Temp | 5000K (Cool) |
| Lumens | 6,728 lm |
| Efficacy | 136.5 lm/W |
| Color Accuracy | 72 CRI |
| L70 Lifespan | 60,000 Hours |
| Type | Constant Current |
| 120V | 0.42A |
| 208V | 0.22A |
| 240V | 0.19A |
| 277V | 0.19A |
| Input Watts | 49.3W |
Dimensions
Weight: 4.6 lbs
Technical Specifications
Compliance
UL Listed
Suitable for wet locations. Suitable for ground mounting.
IESNA LM-79 & LM-80 Testing
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PSRDR38U
DLC Product Code: PSRDR38U
Electrical
Driver
Constant Current, Class 2, 50/60 Hz, 2kV, 120 - 277VAC, 120V: 0.42A, 208V: 0.22A, 240V: 0.19A, 277V: 0.19A
Dimming Driver
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.
THD
2.85% at 120V, 6.51% at 277V
Power Factor
100% at 120V, 95.8% at 277V
Surge Protection
+/- 1 kV line to line (differential mode)/ +/- 2 kV line to common mode ground (tested to secondary ground) on AC power port, +/- 0.5 kV for outdoor cables
