RWLED3T105SFRG/PCS2

Spec Sheet IES File Instructions Spec Sheet EZ Layout

RWLED3T105SFRG/PCS2

Ideal for entrance roadways, collector roads, and single-sided roads

27 year lifespan dramatically reduces maintenance and re-lamping costs

Precision optics deliver maximum downward street side lumens with uniformity and minimal glare

Industry-leading 5G vibration rating per ANSI C136.31

Easy-access electrical compartment makes wiring fast and secure

10-Year, No-Compromise Warranty

View Technical Specs

View Price & Availability

Performance

Watts	105W
Color Temp	5000K (Cool)
Lumens	12,476 lm
Efficacy	114.6 lm/W
Color Accuracy	70 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V	0.58A
240V	0.50A
277V	0.44A
Input Watts	108.9W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 31.0 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations as a downlight

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: P00001783

IP Rating

Ingress protection rating of IP66 for dust and water

Performance

Lifespan

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

Optical

IES Classification

The Type III distribution is ideal for roadway, general parking and other area lighting applications where a larger pool of lighting is required. It has greater streetside (transverse) throw, allowing the light to project outward and fill the area.

Construction

Vibration Rating

Industry-leading 5G vibration rating per ANSI C136.31

Electrical

Drivers

Two Drivers Constant Current, Class2, 1400mA, 100-277V, 50/60Hz, 0.8A, Power Factor 99%

THD

5.9% at 120V, 11.9% at 277V

Power Factor

99.6% at 120V, 94.5% at 277V
