SHARK2-18YNW/480/D10

Spec Sheet IES File LM79 Instructions Spec Sheet EZ Layout

Impact-resistant linear washdown

Ideal for tunnels and stairwells

Mounting options: Chain, junction box, angled surface mount or vandal-resistant surface mount

IP66 Rating protects against dust & water ingress

5-Year, No-Compromise Warranty

100,000-Hour LED lifespan

View Technical Specs

View Price & Availability

Performance

Watts	18W
Color Temp	3500K (Warm Neutral)
Lumens	2,236 lm
Efficacy	111.8 lm/W
Color Accuracy	84 CRI
L70 Lifespan	100,000 Hours

Type	Constant Current
120V
208V
240V
277V
Input Watts	20W

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 7.1 lbs

Technical Specifications

Compliance

UL Listed

Suitable for wet locations

UL 94

5VA flame classification

NSF

NSF Certified by Public Health and Safety

IP Rating

Ingress protection rating of IP66 for dust and water

NEMA Rating

NEMA 4X rating indicates an enclosure protects against windblown dust and rain, splashing and hose-directed water, and offers additional corrosion resistance.

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
DLC Product Code: PMJRQPWA (Stairwell and Passageway Luminaires)
DLC Product Code: PXXP94CH (Direct Linear Ambient Luminaires)

Electrical

Driver

Constant Current, Class 1, 480V, 50/60 Hz, 480V: 0.05A

Dimming Driver

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

THD

5.93% at 480V

Power Factor

99% at 480V

Construction

Length

2 ft
