TNF/LCB

24V DC - 205lm/ft - 4.3W/ft

Non-pixelated light diffusion enables the product to be freely bent in any direction, vertically or horizontally

Field-cuttable for shorter runs with a max run of 32ft. Can be linked with connectors (sold separately)

Easy installation with clips, fixed channel, and bendable channel (sold separately)

Tunable white 2700-6500K, requires Lightcloud Blue controller (sold separately)

60W & 96W Indoor or outdoor rated drivers available (sold separately)

50,000-hr rated life, Title 24 Compliant, and 5-year limited warranty

View Technical Specs

View Price & Availability

Performance

Watts	2.5W/ftW
Color Temp	2700-6500K
Lumens	135lm/ft lm
Efficacy	54
Color Accuracy	90 CRI
L70 Lifespan	50,000 Hours

Type
120V	17 mA/LED
208V
240V
277V
Input Watts	2.5W/ftW

EZ-Layout

Create Custom Lighting Layout

Dimensions

Weight: 3.2 lbs

Technical Specifications

Performance

Product Type

Dual Flex Silicone Wet Rated Neon Tape Light Tunable White

Description

NEOFLEX recreates classic neon with seamless, dot-free illumination. Designed to bend vertically and horizontally, it is IP67 rated for indoor and outdoor applicatio

Input Wattage

2.5 W/ft

Lumens

120lm/ft (WW)
135lm/ft(CW)

Efficacy

48-54lm/W

L70 Lifespan

50,000-Hour LED lifespan based on IES LM-70 results

Electrical

Dimmable

Yes, using Lightcloud Blue
This product will not operate properly when connected to a standard (incandescent) dimmer or dimming control.

Input Voltage

DC24V

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

LED Characteristics

Beam Angle

120°

Color Temperature

Default: 3000K
Tunable white 2700-6500K using Lightcloud Blue

Color Accuracy (CRI)

90 CRI

R9 Value

High color performance with R9 greater than 60

Color Consistency

<5-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

Installation

Field Cuttable Increment

Cuttable every 1.97"

Mounting

Easy installation with clips, fixed channel, and bendable channel (sold separately)

Construction

Length

16.4 ft

Max Linkable Run

Varies by driver. Multiply watt per foot by the number of feet. Should exceed driver capacity

PCB Width

Width: 16mm
Height: 16mm

Light Source

COB LED White

Material Construction

Single-axis top-bend design for controlled curved installations.

Light Effect

Soft linear lighting performance

Compliance

Listings

UL2108

Environment

Suitable for use indoors and outdoors in dry, damp, or wet environments.

IP Rating

IP67

California Title 24 JA8 Compliant

Can be used to conform with the requirements of California Title 24 Part 6.

California Energy Commission (CEC) Status

Lawful for Sales in California

IESNA LM-79 & LM-80 Testing

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

RoHS

Mercury and UV free. RoHS-compliant components.

FCC

Complies with Part 15 of the FCC Rules

Other

Compatible Products

LCBLV/TW
Lightcloud Blue controller for tunable white tape light

Field Wiring Accessories

TPF3NF
3-Pin Power Feed Kit

Mounting Accessories

TAP16
16mm Wide Aluminum Straight Channel

TAP16TL
Trimless 16mm Wide Aluminium Profile

TSG
Silicone glue

TB16
16mm Wide Mounting Brackets

TBB16
16mm Wide Bendable Aluminum Channel

Compatible Drivers

TND-96
96W Indoor/Outdoor Driver ON/OFF

5-Year Limited Warranty

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
