LCTWIST/K
LCTWIST/K
- Advanced daylight sensing
- Utility-grade energy metering
- Remote control and setup from Lightcloud Web App
- Communicates over secure wireless mesh network - no internet required
Dimensions
Weight: 0.4 lbs
Technical Specifications
Product Details
Application
Roadway fixtures
Mounting Type
ANSI C136.10/C136.41 Receptacle
Compliance
IP Rating
Ingress protection rating of IP65 for dust and water
Construction
Operating Temperature Range
-40°C - 70°C
Electrical
Input
120-277VAC, 50/60Hz
Load Switching Capacity
5A @ 120VAC, Electronic Ballast
5A @ 277VAC, Electronic Ballast
Dimming Circuit: 50mA @10VDC
5A @ 277VAC, Electronic Ballast
Dimming Circuit: 50mA @10VDC
Connection Type
ANSI C136.10/C136.41 Receptacle
Wireless Range
Line of Sight
1,000 ft
Obstructions
100 ft
Other
Warranty
10-year full hardware warranty with 100% repair/replacement coverage for all properly installed devices. See Lightcloud Warranty Terms.
